Gamber Johnson 7170-0930-02, KIT: Panasonic Toughpad FZ-G1 Docking Station, Dual RF, VESA Hole Pattern with LIND 11-16V Auto Power Adapter with Bare Wire Lead
ID:
#13714
SKU:
7170-0930-02
KIT: Panasonic Toughpad FZ-G1 Docking Station, Dual RF, VESA Hole Pattern with LIND 11-16V Auto Power Adapter with Bare Wire Lead
This Panasonic Toughpad FZ-G1/G2 docking station accommodates the tablet's extended battery, smart card reader, rear hand strap and large bumper guards. This docking station features full port replication to connect peripherals, dual antenna pass-through, and a VESA 75mm mounting pattern. This Kit includes a LIND power adapter.
Antenna Pass-Through
- Dual RF (TNC)
Port Replicator
- Panasonic certified electronics
- (1) Ethernet - RJ45
- (1) Serial - D-sub 9-pin
- (1) VGA - D-sub 9 pin
- (1) HDMI - 19 pin
- (2) USB 3.0 (900mA) - 9 pin
- Dual RF Pass-through (optional) - TNC
- Power input - 16VDC
- Antenna Switch
Power Supply
- Includes LIND 11-16V Auto Power Adapter with Bare Wire Lead (7300-0460)
Features
- Compatible with the Panasonic Toughpad FZ-G1 and G2 tablet computers with small or large bumper guards
- Panasonic certified electronics
- Docking station accommodates the tablet's extended battery, smart card reader, rear hand strap and large bumper guards.
- Access to all tablet control buttons and ports while tablet is docked
- Easy docking and release, Insert computer into the docking station, push top of dock down and engage lock to dock computer
- Upward-facing I/O ports; integrated cable strain relief and cable management system
- Keyed lock for theft deterrence
- VESA 75mm mounting pattern
- Rounded edges to enhance personal safety
- Gamber-Johnson rugged construction and reliability
- Composite design for reduced weight and durability
Certificates & Testing
- Toughbook Certified
- MIL-STD 810G Shock/Vibration Tested
- MIL-STD 810G Environmental Testing: Humidity, High/low temperature, (storage/operational)
- Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
- RoHS, FCC, CE, C-TICK, UKCA
- SAE J1455 Shock Crash Hazard Test
Kit Includes
- Panasonic FZ-G1 / G2 Docking Station
- Mounting Hardware
- LIND 11-16V Auto Power Adapter
- Installation Instructions
Warranty
- 3-Year Limited Warranty
- Explore our extended warranty program
